Meter type fast twist fitting
PL Copper Twist Right-Angle Elbow Pneumatic Fittings
Nickel Plated Copper Quick Screw Connector Pneumatic Air Fitting Straight Joint Locking Nut PC4 PC6 PC8 PC10 PC12C10 PC12
Specifications
- Working medium
- Compressed air
- Material
- Copper
- Surface treatment
- Nickel plated
- Operating pressure
- 0-1.0Mpa
- Working Temperature
- 0-60 degree
PL All-Brass Male Elbow Pneumatic Compression Fitting
The PL Series is an all-brass male elbow compression fitting designed to connect metric pneumatic tubing to a female threaded port at a 90-degree angle. It is an ideal solution for valves, cylinders, manifolds and air preparation equipment where installation space is limited or where tubing cannot be routed in a straight line.
The series supports tubing from 4 mm to 16 mm outside diameter and male threads from R1/8 to R1/2.
Key Features
All-Brass Construction
The fitting body, compression nut and threaded section are manufactured from brass, providing high mechanical strength, dimensional stability and dependable service life.
Secure Compression Connection
The screw-tightened tube connection creates a firm mechanical grip. It is particularly suitable for pneumatic lines exposed to machine vibration, movement or repeated operating cycles.
90-Degree Configuration
The elbow design redirects the pneumatic tube through 90 degrees, reducing the need for tight tube bends and making installation easier in confined spaces.
Corrosion-Resistant Metallic Finish
The silver-colored metallic surface provides a clean industrial appearance and helps protect the brass body against oxidation and normal environmental exposure.
Multiple Tube and Thread Combinations
Available configurations cover:
- Tube outside diameters from 4 mm to 16 mm
- R1/8, R1/4, R3/8 and R1/2 male threads
- Tube dimensions from 4 × 2.5 mm to 16 × 12 mm
Product Specifications
Item | Specification |
Product series | PL |
Fitting type | Male elbow compression fitting |
Configuration | 90-degree tube-to-male-thread connector |
Body material | Brass |
Exterior | Silver-colored corrosion-resistant metallic finish |
Tube connection | Screw-tightened compression connection |
Thread connection | Male R thread |
Tube range | 4–16 mm outside diameter |
Thread range | R1/8–R1/2 |
Standard tube system | Metric |
Recommended medium | Compressed air |
Working pressure | Confirm according to the tubing and application |
Operating temperature | Confirm with the supplier before ordering |
Internal sealing materials | Confirm according to the selected version |
